ALpharma B - Pharmaceutical Boxes Labeling System

Integrated system for printing and applying labels to pharmaceutical shaped cases. For labeling with either bar code labels (tags, vignettes) or tamper-evident angle labels folded along the flaps (up to 200 pcs/min).

This product line has a stainless-steel base and complete protective cabin.

To the side of the loading unit are two motorized belts to align the products (speed synchronized with the first conveyor section) and another two faster ones to space out the products evenly.

The labeling is performed on two sides when the boxes are stabilized by an upper motorized belt.

The labelers (ALritma) have capacitive sensors installed to read transparent labels.

Label folding is performed by two shaped stainless steel plates and two rollers which press the folded part over the edge.

At the end of the line two special sensors (one for each side) activate an expulsion system for non-labeled products, and reject them in a bin.

Technical specifications ALpharma B

Power supply

400V 50 Hz three-phase

Power Consumption

1 Kw

Performances

up to  200 pcs/min
