ALritma T – High Speed Print & Apply Label Applicator

ALritma T is one of the fastest and most efficient print and apply label applicator available on the market today, able to print and apply over 200 labels/minute.

With a print speed of up to 16" per second, combined with a label application speed of up to 200’/min (130’/min standard) and the advantage of ribbon saving.

The key to the speed of ALritma T is its print unit control system, which uses a swinging arm to adapt the printer's operation to that of the label application on the basis of the loop of labels between the two different functions. The unit is thus able to print and apply simultaneously and independently, and is at least twice as fast as any traditional real-time print-apply unit.

ALritma T is also easy-to-use, as it is not limited to predetermined sizes for single labels, and does not require manual adjustment (for example when changing the label position). The unit is controlled by a microprocessor equipped with a multilingual touchscreen, which provides the user with all the most common adjustments on a simple main screen. Once these adjustments have been entered, up to 40 formats can be stored (product/label combinations), significantly simplifying and speeding up format changes.

ALritma T does not require compressed air and can operate, when necessary, as a normal applicator: an extremely flexible tool, above all for the application of promotional labels, where sometimes a variable price is printed and applied, and other times only a preprinted label is applied.

The available functions and optional accessories are the same as for the ALritma label applicator.

Main Features

  • High-speed printing and deferred application: up to 300 labels/min -  130’/min
  • Independent label loop control arm provides the possibility to operate in application-only mode
  • No compressed air is require - Extremely intuitive and easy-to-use
  • Incredibly flexible, allowing use of different size and shape labels, without having to change machine components.

Technical specifications ALritma T

Label width max mm.

according to the printer

Speed

40 mt/min

Controls

Display touch screen

Memory capacity

40 formats

Machine body protection

according to the printer

Unwind unit Ø

300 mm

Standard alarms

end of roll - web break - drag open

Missing labels recovery

current

Near end of roll check

optional

Pneumatics applicators

optional

Encoder

optional

Transparent label sensor

optional

Coder / TT printer

SATO module or compatibles

AC Power

240 V - 50 Hz - 400 W
