ALstep - Compact Label Applicator

The ALstep automatic label applicator is a compact, low-cost applicator for pressure-sensitive labels which can be easily integrated into existing packaging lines.

ALstep is based on a robust and reliable mechanical system which can be installed in particularly small areas; this is also due to the side-access web threading which allows fast and easy change-over of labels.

The ALstep units are available in the following versions:

  • S (label width up to 100 mm), speed 30 m/min
  • M (label width up to 200 mm), speed 20 m/min
  • T with integrated SATO thermal printer
  • E (lowest cost model with label width up to 100 mm) speed 15 m/min.

A microprocessor allows all the labelling parameters to be entered via a display and function keys and then stored in EEPROM so they are always available when the unit is turned on. They are:

  • Label pre-dispensing length
  • Label dispensing speed
  • Labeling delay
  • Automatic recovery of missing labels
  • Progressive counter
  • End-of-roll and web break alarm
  • Output for connection to other systems.

Options

ALstep applicator can integrate the following devices to solve specific labeling problems:

  • Hot foil marker
  • Thermal transfer printer (ALstep T version)
  • Pneumatic and air-blow applicators
  • Near end-of-roll monitoring
  • Encoder speed control
  • Sensor for transparent labels.

Techinal specifications ALstep E

Label Width

Max 100 mm.

Max Speed

15 m/min

Control

Contraves

Label Position

Manual

End-of-roll and web break alarm

Standard

Missing Labels Recovery

Not availabe

Pieces Counter

Not availabe

Transparent Label Sensor

Optional

Coder / TT Printer

Not availabe

Near End of Reel Check

Not availabe

Pneumatic Application

Not availabe

Encoder

Not availabe

Unwind Unit Diameter

300 mm.

Power Supply

240 V - 50 Hz

Power Consumption

400 W

ALstep S/M

Label Width

Max 100 mm.(S) - 200 mm.(M)

Max Speed

30 m/min(S) - 20 m/min(M)

Control

Display and function buttons

Label Position

Elettronic

End-of-roll and web break alarm

Standard

Missing Labels Recovery

Standard

Pieces Counter

Standard

Transparent Label Sensor

Optional

Coder / TT Printer

Optional

Near End of Reel Check

Optional

Pneumatic Application

Optional

Encoder

Optional

Unwind Unit Diameter

300 mm.

Power Supply

240 V - 50 Hz

Power Consumption

400 W
