ALritma - High Performance Label Applicator

ALritma is a high-performance label applicator machine designed to be integrated into packaging lines in which production speed and reliability are the primary requirements.

ALritma label applicators are based on an innovative mechanical structure which matches strength with versatility. It is available in three versions, S, M and L, for label widths up to 4”, 8” and 12" respectively.

The ALritma label applicator is controlled by a powerful microprocessor with a touch screen display. The most frequently used parameters are displayed via intuitive icons which represent the various functions and provide advanced management, relieving the operator of the need to perform complex mechanical adjustments and noticeably speeding up format changes.

Displayed parameters

  • Pre-dispensing adjustment in tenths of a mm (1/250")
  • Speed adjustment in 0.1 m (4")/min increments
  • Labeling delay adjustment in mm
  • Acceleration/deceleration ramp adjustment
  • Storage of different label formats
  • Automatic recovery of missing labels
  • Progressive and countdown piece counter
  • Automatic removal of double product detection
  • Shift register between product sensor and label application point
  • End-of-roll alarm and web break alarm
  • Output for connection to other systems.

Options

In addition to sophisticated standard devices, ALritma labelers can be equipped with an array of options to increase their performance and range:

  • Hot-foil printing unit
  • Supplementary unwinding unit
  • Unwinding unit for larger reels up to 400 mm (16")
  • Hot-foil printing unit
  • Sensor for transparent material labels
  • Pneumatic and air-blow applicators
  • Near-end-of-reel sensor
  • Correct label application monitoring device
  • Non-stop control for sequentially placed applicators
  • Automatic speed control, via encoder
  • Serial Interface for connection to PC.

Technical specifications ALritma S / M / L

Label Width Max mm.

100(S); 200(M); 300(L)

Speed  (m/min)

50 (S); 50 (M); 40 (L)

Controls

Display touch screen

Memory Capacity

40 formats

Machine Body Protection

IP55

Ø Unwind unit

300 mm

Standard Alarms

End Of Roll / Web Break / Drive Open

Missing label recovery

Standard

Near end of roll check

Optional

Pneumatics applicator

Optional

Encoder

Optional

Transparent label sensor

Optional

Coder / TT Printer

Optional

Power Supply

240 V - 50 Hz - 400 W

Power Consumption

400 W



Label Applicators - Labelers

ALstep and ALritma self-adhesive automatic label applicators work every day in our clients' packaging lines, spread over 50 countries around the world.
